AR27.10-P-0500EV Remove/Install Transmission With Torque Converter




AR27.10-P-0500EV Remove/Install Transmission With Torque Converter
TRANSMISSION 722.9 (except 722.96) in MODEL 212
TRANSMISSION 722.9 (except 722.96) in MODEL 218





Shown on model 212.072

1 Shield
2 Ground cable
3 Electrical line
4 Bracket
5 Transmission
7a Rear engine crossmember
7b Rear engine mount
16 Bracket
17 Bolts
20v Front flex disk
A80 Intelligent servo module for DIRECT SELECT





5 Transmission
8 Screw
9 Torque converter
































001 589 65 09 00
Wrench socket





129 589 00 91 00
Set of stop plugs





115 589 03 59 00
Long wedge





168 589 00 62 00
Grab handle





126 589 04 31 00
Parallel support
