GF27.60-P-3027AHX Wet Clutch Control Pressure, Function

GF27.60-P-3027AHX Wet Clutch Control Pressure, Function
TRANSMISSION 722.930 up to 31.5.11, 722.931 as of 1.6.11
in MODEL 212.0/ 2

Function requirements for wet clutch control pressure, general
^ Status "Circuit 87 ON"
^ Circuit 61 ON

Wet clutch control pressure, general
The regulating valve for the wet clutch has variable control pressure applied to it.
The wet clutch control pressure is adapted to the respective operating state through the wet clutch control solenoid valve (Y3/8y9) which is actuated by the fully integrated transmission control unit (Y3/8n4).
