GF27.55-P-2000AHX Transmission Oil Cooling, Function

GF27.55-P-2000AHX Transmission Oil Cooling, Function
TRANSMISSION 722.930 up to 31.5.11, 722.931 as of 1.6.11
in MODEL 212.0/ 2

Function requirements for transmission oil cooling, general
^ Status "Circuit 87 ON"
^ Status "Circuit 61 ON"

Transmission oil cooling, general
To reach the operating temperature of the transmission quicker, the transmission oil is heated by the engine's cooling circuit.
Transmission oil cooling lowers the temperature of the transmission oil and thus prevents overheating damage in the transmission.

Function sequence for transmission oil cooling
The transmission oil is drawn out of the transmission oil pan by a mechanical pump in the transmission and is pumped via the feed to the transmission oil heat exchanger (which is integrated in the engine radiator). The transmission oil then flows from the transmission oil heat exchanger to the transmission oil thermostat.
At a transmission oil temperature <90 °C, the trans mission oil thermostat directs the transmission oil back to the transmission via the return.
At a transmission oil temperature >90 °C, the trans mission oil thermostat opens and the transmission oil flows through the transmission oil cooler, before it flows back through the return to the transmission.
