GF82.95-P-2010FLU MB Information, Function

GF82.95-P-2010FLU MB Information, Function
- with CODE (359) TELE AID emergency call system

Function requirements
^ Circuit 30g On
^ Emergency call system authorized and operating properly
^ The vehicle-related MB Info call service is authorized separately
^ An emergency call system control unit (N123/4) communication module authorized for the vehicle-related MB-Info call service is configured ex-factory with the telephone number of the corresponding service provider
^ The driver is registered and authorized with the service center
^ One mobile phone network is available in sufficient strength and quality
^ Triggering of an MB Info call through pressing the MB Info button (S93/6s1) for t > 0.5 s
^ A higher-priority vehicle-related service is not active

MB Info general
The MB Info call function enables the driver to call up information on Mercedes-Benz brand products as well as further voice-based services (e.g. hotel booking).
This vehicle-related service is primarily an oral information service that is provided via the communications module integrated into the emergency call system control unit.
The MB Info function consists of the following subfunctions:
^ MB-Info call function sequence
^ Function sequence, destination entry by service center or special destinations ("Points of Interest") (with code (512) COMAND APS with DVD changer)

MB-Info call function sequence
The MB-Info button is read in by the emergency call system control unit via a direct line. The emergency call system control unit then completes a voice connection to the service center. After the service center replies with a special tone, the emergency call system control unit automatically sends an SMS with the following data to the service center over the integrated communication module:
- Vehicle position
- Customer identification data
- Vehicle identification data

The communication module integrated in the emergency call system control unit transmits and receives the mobile phone signals via the following route:
- Direct line
- Multifunction antenna (A28/11)

The MB-Info button's integrated light emitting diode flashes as long as the MB-Info call is activated. This is also indicated in the instrument cluster (A1) and on the Audio/COMAND display (A40/8).

In the event of an MB Info call, other vehicle-related services with a lower priority (e.g. vehicle remote door unlock) are interrupted.

In the event of a multifunction antenna failure (e.g. defective because of rollover) the emergency call system control unit automatically uses the emergency call system antenna (A2/52) to transmit the mobile phone signals.

Function sequence, destination entry by service center or Points of Interest, with code (512) COMAND APS with DVD changer
During an MB Info call, for example, the address of a hotel can be loaded into the navigation module in the COMAND operating, display and controller unit (A40/3).
The service center transmits the address of the hotel to the COMAND control unit via the following route using mobile phone signals:
- Multifunction antenna
- Direct line
- Emergency call system control unit
- Diagnostic CAN (CAN D)
- Front SAM control unit with fuse and relay module (N10/1)
- Interior CAN (CAN B)

Detailed information on starting the navigation can be found in the system description for the COMAND controller unit.

The destination entered by the service center and the Points of Interest are displayed on the Audio/COMAND display by the emergency call system control unit via the following route:
- Diagnostic CAN
- Front SAM control unit with fuse and relay module
- Interior CAN
- COMAND controller unit
- Low voltage differential signal (LVDS) line
