AR09.41-P-8625SXI Remove/Install Charge Air Hose Downstream of the Charge Air Cooler

AR09.41-P-8625SXI Remove/install Charge Air Hose Downstream Of The Charge Air Cooler
- ENGINES 642 in MODEL 207, 212, 218, 221

Shown on engine 642.910







1 Charge air hose downstream of charge air cooler
2 Charge air cooler
3 Charge air duct downstream of charge air cooler
