Home >> Mercedes Benz >> 2011 >> E 350 BLUETEC (212.024) V6-3.0L DSL Turbo (642.850) >> Repair and Diagnosis >> Accessories and Optional Equipment >> Cellular Phone >> Description and Operation >> GF82.70-P-2017FLJ Mobile Phone System, Accepting Calls, Rejecting Calls and Toggling, Function

GF82.70-P-2017FLJ Mobile Phone System, Accepting Calls, Rejecting Calls and Toggling, Function



GF82.70-P-2017FLJ Mobile Phone System, Accepting Calls, Rejecting Calls And Toggling, Function
- with CODE (527) COMAND APS with single DVD drive (with navigation)
- with CODE (498) Japan version
- basic telephony

Function requirements
^ Circuit 30g
^ Mobile phone and COMAND controller unit (A40/3) switched on
^ One mobile phone network is available in sufficient strength and quality
^ Compatible mobile phone connected over the Japan adapter cable electrical connector (X39/46) to the communications control unit (N123/6) or a Bluetooth-compatible mobile phone paired with the COMAND controller unit is located in the vehicle

A Bluetooth-compatible mobile phone can only be operated in the vehicle if a mobile phone is not connected to the adapter cable electrical connector.

In order to be able to operate a Bluetooth-compatible mobile phone that is authorized on the COMAND controller unit in the vehicle, the mobile phone must support hands-free profile (HFP) 1.0 or 1.5.
More information is available under:
http://www.mercedes-benz.com/connect

General
The mobile phone can be used by the user to initiate, terminate or toggle a telephone call to another person in the cellular telephone system network or in the fixed-line network.
The accept call, reject call and toggle functions consist of the following subfunctions:
^ Function sequence, call signal
^ Accept call function sequence using mobile phone buttons
^ Accept call function sequence via function keys on the COMAND controller unit
^ Accept call function sequence over Audio/COMAND control panel (A40/9)
^ Accept call function sequence over left multifunction steering wheel button group (S110) and right multifunction steering wheel button group (S111)
^ Function sequence, telephone call in hands-free mode
^ Reject call function sequence using mobile phone buttons
^ Reject call function sequence via function keys on the COMAND controller unit
^ Reject call function sequence over Audio/COMAND control panel
^ Reject call function sequence via left multifunction steering wheel button group and right multifunction steering wheel button group
^ Toggle function sequence over mobile phone buttons
^ Toggle function sequence via function keys on the COMAND controller unit
^ Toggle function sequence over Audio/COMAND control panel
^ Toggle function sequence via left multifunction steering wheel button group and right multifunction steering wheel button group

The system is described using a mobile phone connected to the adapter cable electrical connector as an example. Deviations from this are indicated with the symbol.

The following options are available to accept, reject or toggle a call:
- Buttons on the mobile phone
- Function keys on the COMAND controller unit
- Audio/COMAND control panel
- Left multifunction steering wheel button group and right multifunction steering wheel button group

Function sequence, call signal
The mobile phone receives a call signal from the mobile telephone network via the following route:
- Multifunction antenna (A28/11)
- Direct line
- Adapter cable electrical connector

The caller is shown on the display of the mobile phone and the information is forwarded simultaneously in the following way to the COMAND controller unit:
- Adapter cable electrical connector
- Direct line
- Communication control unit
- Direct line

The COMAND controller unit in vehicles (with code (810) Sound system) sends the call tone by means of audio signals to the sound system amplifier control unit (N40/3) over the Media Oriented System Transport (MOST).

From there, the ring tone is transmitted via direct lines to the following speakers:
- Center dashboard speaker (H4/27)
- Left rear surround speaker (H4/54)
- Right rear surround speaker (H4/55) (model 212.2)
- Right rear surround speaker (H4/57) (model 212.0)
- Left front door sound system tweeter (H4/68)
- Right front door sound system tweeter (H4/69)
- Left rear door sound system tweeter (H4/70)
- Right rear door sound system tweeter (H4/71)
- Left front door sound system midrange and bass speakers (H4/72)
- Right front door sound system midrange and bass speakers (H4/73)
- Left rear door sound system midrange speaker (H4/80)
- Right rear door sound system midrange speaker (H4/81)

For the bass speaker (H4/17) (model 212.0) or for the bass speaker (H4/29) (model 212.2), the audio signal is routed from the COMAND controller unit to the sound system amplifier control unit via MOST and from there to the bass speaker via the rear bass speaker amplifier (N40/9) using direct lines.

On vehicles (without code (810) Sound system), the audio signal is output directly by the COMAND controller unit to the following speakers:
- Left front door speaker (H4/1)
- Left front door tweeter (H4/1h1)
- Right front door speaker (H4/2)
- Right front door tweeter (H4/2h1)
- Left rear door speaker (H4/3)
- Left rear door tweeter (H4/3h1)
- Right rear door speaker (H4/4)
- Right rear door tweeter (H4/4h1)

At the same time the COMAND controller unit reduces the volume of the currently active audio source (e.g. the radio) by L = 15 dB. The currently active audio source is not muted until the caller accepts the call (MUTE). This happens internally in the COMAND controller unit.
The caller identification is shown by the COMAND controller unit on the Audio/COMAND display (A40/8) via a low voltage differential signal (LVDS) line. The caller identification is also shown on the multifunction display (A1p13) in the instrument cluster (A1) via the interior CAN (CAN B).

A mobile phone operated via Bluetooth(R) receives the call signal via the mobile phone antenna. The call signal is then forwarded to the COMAND controller unit in the via the following route:
- Bluetooth antenna (A2/91)
- Direct line

Accept call function sequence using mobile phone buttons
Pressing the "Accept call" button on the mobile phone serves to accept the call in hands-free mode. The control signals of the mobile phone buttons are internally processed and forwarded via the following route to the COMAND controller unit:
- Adapter cable electrical connector
- Direct line
- Communication control unit
- Direct line

With a mobile phone operated via Bluetooth(R), the control signals from the mobile phone buttons are processed internally and forwarded to the COMAND controller unit via the following route:
- Bluetooth antenna
- Direct line

Accept call function sequence via function keys on the COMAND controller unit
Pressing the "Accept phone call" button on the COMAND controller unit serves to accept the call in hands-free mode. The control signals of the telephone buttons on the COMAND controller unit are processed internally and forwarded to the mobile phone via the following route:
- Direct line
- Communication control unit
- Direct line
- Adapter cable electrical connector

On a Bluetooth-operated mobile phone, communication takes place between the COMAND controller unit and the mobile phone via the following route:
- Direct line
- Bluetooth antenna

Accept call function sequence over Audio/COMAND control panel
Through the call signal, the call identification is sent by the COMAND controller unit over a low voltage differential signal line to the Audio/COMAND display.
Selecting the "Accept call" function using the Audio/COMAND control panel serves to accept the call in handsfree mode. The control signals from the Audio/COMAND control panel are forwarded via the telematics CAN (CAN A) to the COMAND controller unit. The control signals are then forwarded to the mobile phone via the following route:
- Direct line
- Communication control unit
- Direct line
- Adapter cable electrical connector

On a mobile phone operated via Bluetooth(R), communication takes place between the COMAND controller unit and the mobile phone via the following route:
- Direct line
- Bluetooth antenna

Accept call function sequence via left multifunction steering wheel button group and right multifunction steering wheel button group
The call is accepted in handsfree mode by pressing the accept/ terminate phone call button (S111s3) in the corresponding panel. The control signal of the accept/terminate phone call button are forwarded over the following components to the COMAND controller unit:
- Direct line
- Steering wheel electronics (N135)
- Steering LIN (LIN E1)
- Steering column module control unit (N80)
- Chassis CAN (CAN E)
- Instrument cluster
- Interior CAN

The control signals are then forwarded to the mobile phone via the following route:
- Direct line
- Communication control unit
- Direct line
- Adapter cable electrical connector

Function sequence, telephone call in hands-free mode
After the call has been accepted, the mobile phone receives or transmits the mobile phone signals or data in the following way:
- Multifunction antenna
- Direct line
- Adapter cable electrical connector

The voice input in hands-free mode is picked up by the hands-free system microphone (A67b1) and forwarded to the COMAND controller unit via a direct line.
The voice input is routed by the COMAND controller unit to the mobile phone via the following route:
- Direct line
- Communication control unit
- Direct line
- Adapter cable electrical connector

The voice output is forwarded by the COMAND controller unit in vehicles with code (810) Sound system by means of audio signals to the sound system amplifier control unit via MOST.

From there, the audio signal is transmitted to the following speakers over direct lines:
- Center instrument panel speaker
- Left rear surround speaker
- Right rear surround speaker
- Left front door sound system tweeter
- Right front door sound system tweeter
- Left rear door sound system tweeter
- Right rear door sound system tweeter
- Left front door sound system midrange and bass speakers
- Right front door sound system midrange and bass speakers
- Left rear door sound system midrange speaker
- Right rear door sound system midrange speaker

For the bass speaker, the audio signals are transmitted from the COMAND controller unit to the sound system amplifier control unit via MOST and from there to the bass speaker via the rear bass speaker amplifier using direct lines.

On vehicles without code (810) Sound system, the audio signals are output directly by the COMAND controller unit to the following speakers:
- Left front door speaker
- Left front door tweeter
- Right front door speaker
- Right front door tweeter
- Left rear door speaker
- Left rear door tweeter
- Right rear door speaker
- Right rear door tweeter

With a mobile phone operated via Bluetooth(R), the mobile phone sends or receives the mobile phone signals or mobile phone data via the antenna of the mobile phone. Communication between the COMAND controller unit and the mobile phone takes place via the following route:
- Direct line
- Bluetooth antenna

Generally, after accepting the call, the telephone connection is established in hands-free mode, irrespective of whether the mobile phone is connected to the adapter cable electrical connector or not and operated via Bluetooth(R).
If, after the telephone connection has been established in handsfree mode, a mobile phone attached to the adapter cable electrical connector is disconnected from the adapter cable electrical connector and therefore from the COMAND controller unit, the telephone call is then conducted in "Private mode". If the mobile phone is reattached to the adapter cable electrical connector during a telephone call, the telephone call is then conducted in the handsfree mode again.

On a mobile phone not connected to the adapter cable electrical connector and operated via Bluetooth(R), it is possible to switch to "Private mode" following acceptance of the telephone call in hands-free mode by activating the "Private mode" menu item via the Audio/COMAND control panel and the Audio/COMAND display.

When in "private mode" the user can make a telephone call without other vehicle occupants being able to hear the conversation.

Reject call function sequence using mobile phone buttons
Pressing the "End" button on the mobile phone rejects the call. The control signals of the mobile phone buttons are internally processed and forwarded via the following route to the COMAND controller unit:
- Adapter cable electrical connector
- Direct line
- Communication control unit
- Direct line

With a mobile phone operated via Bluetooth(R), the control signals from the mobile phone buttons are processed internally and forwarded to the COMAND controller unit via the following route:
- Bluetooth antenna
- Direct line

Reject call function sequence via function keys on the COMAND controller unit
Pressing the "End" function key on the COMAND controller unit once puts the call on hold. Pressing the "END" function key on the COMAND controller unit twice rejects the call.
The control signals of the function keys at the COMAND controller unit are processed internally and forwarded to the mobile phone via the following route:
- Direct line
- Communication control unit
- Direct line
- Adapter cable electrical connector

On a mobile phone operated via Bluetooth(R), communication takes place between the COMAND controller unit and the mobile phone via the following route:
- Direct line
- Bluetooth antenna
- Mobile phone Bluetooth(R) antenna

Reject call function sequence over Audio/COMAND control panel
The caller identification is shown on the Audio/COMAND display by the COMAND controller unit via an LVDS line by means of the call signal.

By selecting the "Reject" function the call is then rejected. The control signals from the Audio/COMAND control panel are forwarded over the telematics CAN to the COMAND controller unit. The control signals are then forwarded to the mobile phone via the following route:
- Direct line
- Communication control unit
- Direct line
- Adapter cable electrical connector

On a mobile phone operated via Bluetooth(R), communication takes place between the COMAND controller unit and the mobile phone via the following route:
- Direct line
- Bluetooth antenna

Reject call function sequence via left multifunction steering wheel button group and right multifunction steering wheel button group
Pressing the accept/terminate phone call button in the corresponding subfield rejects the call. The control signal of the accept/terminate phone call button are forwarded over the following components to the COMAND controller unit:
- Direct line
- Steering wheel electronics
- Steering LIN
- Steering column module control unit
- Chassis CAN
- Instrument cluster
- Interior CAN

The control signals are then forwarded to the mobile phone via the following route:
- Direct line
- Communication control unit
- Direct line
- Adapter cable electrical connector

On a mobile phone operated via Bluetooth(R), communication takes place between the COMAND controller unit and the mobile phone via the following route:
- Direct line
- Bluetooth antenna

Toggle function sequence over mobile phone buttons
If another call signal is received during a telephone call then it is displayed by the COMAND controller unit over a low voltage differential signal line on the Audio/COMAND display. The telephone call can now be accepted or rejected via the buttons on the mobile phone.
The control signals of the mobile phone buttons are internally processed and forwarded via the following route to the COMAND controller unit:
- Direct line
- Adapter cable electrical connector
- Direct line

If the incoming call is accepted, it is activated in hands-free mode and the existing call is put on hold. If the incoming call is rejected, the existing call remains active in hands-free mode.

On a mobile phone operated via Bluetooth(R), communication takes place between the COMAND controller unit and the mobile phone via the following route:
- Direct line
- Bluetooth antenna

Toggle function sequence via function keys on the COMAND controller unit
If another call signal is received during a telephone call then it is displayed by the COMAND controller unit over a low voltage differential signal line on the Audio/COMAND display. The telephone call can now be accepted or rejected using the function keys on the COMAND controller unit. The control signals from the function keys on the COMAND controller unit are processed internally. If the incoming call is accepted, it is activated in handsfree mode and the existing call is put on hold. If the incoming call rejected, the existing call remains active in hands-free mode.

On a mobile phone operated via Bluetooth(R), communication takes place between the COMAND controller unit and the mobile phone via the following route:
- Direct line
- Bluetooth antenna

Toggle call function sequence over Audio/COMAND control panel
If another call signal is received during a telephone call then it is displayed by the COMAND controller unit over a low voltage differential signal line on the Audio/COMAND display.
The telephone call can now be accepted or rejected via the Audio/ COMAND controller unit. The control signals from the Audio/ COMAND control panel are forwarded over the telematics CAN to the COMAND controller unit. If the incoming call is accepted, it is activated in hands-free mode and the existing call is put on hold. If the incoming call is rejected, the existing call remains active in hands-free mode.

On a mobile phone operated via Bluetooth(R), communication takes place between the COMAND controller unit and the mobile phone via the following route:
- Direct line
- Bluetooth antenna

Toggle function sequence via left multifunction steering wheel button group and right multifunction steering wheel button group
If another call signal is received during a telephone call then it is displayed by the COMAND controller unit over a low voltage differential signal line on the Audio/COMAND display.
By pressing the accept/terminate phone call button in the corresponding subfield, the call can be accepted or rejected. The control signal of the accept/terminate phone call button is forwarded to the COMAND controller unit via the following components:
- Direct line
- Steering wheel electronics
- Steering LIN
- Steering column module control unit
- Chassis CAN
- Instrument cluster
- Interior CAN

If the incoming call is accepted, it is activated in hands-free mode and the existing call is put on hold. If the incoming call is rejected, the existing call remains active in hands-free mode.

On a mobile phone operated via Bluetooth(R), communication takes place between the COMAND controller unit and the mobile phone via the following route:
- Direct line
- Bluetooth antenna
