Muffler: Service and Repair

AZ49.10-P-0018EW Retrofit Sport Muffler
-ENGINES 272, 276 in MODEL 212.0, 204.0
- except CODE (494) USA version





Shown: standard exhaust system for model 212

1 Left rear muffler
2 Right rear muffler
3 Exhaust gas pipes
4 Rubber bushing

Dimension:

A 215 mm
