AR01.30-P-5800RVK Remove/Install Cylinder Head

AR01.30-P-5800RVK Remove/Install Cylinder Head
ENGINES 113.995 in MODEL 230.472





2 Fan shroud
3 Poly-V belt
4 Air cleaner housing
5 Resonance tube
6 Resonance unit
7 Right cylinder head cover
9 Left cylinder head cover
12 Chain tensioner
13 Intake manifold
15 Coolant line
16 Camshaft sprockets
17 Camshaft bearing bridges
18 Oil filter housing with oil-water heat exchanger





20 Cylinder head bolts to timing case cover
21 Cylinder head bolts M11 B141.5
22 Left cylinder head
23 Right cylinder head
24 Left cylinder head gasket
25 Right cylinder head gasket
26 Fitting sleeves


























001 589 72 21 00
Torque wrench





119 589 04 63 00
Pressure hose





112 589 00 32 00
Locating plate





112 589 01 32 00
Locating plate





112 589 00 01 00
Open end wrench





112 589 01 03 00
Insertion tool





000 589 03 10 00
Screwdriver insert
