AR27.19-P-0200A Remove/Install Electrohydraulic Controller Unit (Transmission Installed)

AR27.19-P-0200A Remove/Install Electrohydraulic Controller Unit (Transmission Installed)
TRANSMISSION 722.6 in MODEL 129, 140, 163, 170, 202, 208, 210, 211, 215, 220, 230 (except, 220.874 /876)
TRANSMISSION 722.6 in MODEL 461, 463 (except 461.331, 463.270 /271)





2 Transmission housing
3 Transmission oil pan
3a Sprag
3b Screw
4 Oil drain screw
5 Oil filter
19a Screw
21 Pilot bushing
26 Plug-in connector
62 Heat shield
69 Magnet

Y3/6 Electrical control unit

a Hole for rpm sensor n3
b Hole for rpm sensor n2
