GF82.61-P-4001TJ Destination-Oriented Navigation In Non-Digitalized MAP Area, Function

GF82.61-P-4001TJ Destination-Oriented Navigation In Non-Digitalized Map Area, Function
- with CODE (529) HIGH Class Japan


When traveling outside the digitized map area (e.g. company grounds, multi-level car parks, dirt roads, etc.), but still within the digital versatile disk (DVD)-ROM map boundary, the navigation processor of the COMAND operating, display and controller unit (A40/3) switches over to "Destination-oriented navigation in non-digitized map area". The message "OFF ROAD" appears on the COMAND operating, display and controller unit (A40/3) display. If the vehicle is outside the DVD-ROM map boundary (outside the country), the message "OFF MAP" appears.. In both cases, only basic position finding (dead reckoning) with correction by global positioning system (GPS) is performed.
Limited destination-oriented navigation takes place while only specifying:
^ Straight-line distance to the destination
^ Direction to destination (as an arrow)

After reentering the digitized map area, the system automatically continues with "Destination-oriented navigation in digitized map area".
With the aid of GPS, the possible roads are determined on which the vehicle could be located. During this process a slight delay in the destination-oriented navigation may result.

When the message "OFF MAP" appears, complete destination-oriented navigation can be continued by inserting the proper DVD-ROM for the foreign country.

The time between the COMAND operating, display and controller unit (A40/3) and the instrument cluster (A1) must be synchronized on journeys in other "time zones" (time shift, time change).
