GF82.20-P-2007R Switch Interior Lighting on By Means of Anti-Theft Alarm, Function

GF82.20-P-2007R Switch Interior Lighting On By Means Of Anti-Theft Alarm, Function

If an alarm is triggered by the anti-theft alarm system (ATA), the front dome lamp is switched on without being dimmed. If the alarm is canceled, the lamp is again switched off.

Actuation
^ In the event of an ATA alarm, the message "ATA switch interior lamp on" is transmitted by the driver-side SAM control module (N10/10) over the interior CAN.
^ The overhead control panel control module (N70) reads this message and operates the dome lamp (N70e1).
