GF82.20-P-2007T Switch Interior Lighting on By Means of Anti-Theft Alarm, Function

GF82.20-P-2007T Switch Interior Lighting On By Means Of Anti-Theft Alarm, Function

Function
If the anti-theft alarm system (ATA [EDW]) has triggered an alarm, the front dome lamp (N70e1) and the rear interior lamp (E15/3) are switched on without dimming.
If the alarm is canceled, the front dome lamp (N70e1) and the rear interior lamp (E15/3) are switched off again.

In Model 211.6, depending on equipment and special body, the number and position of the interior lamps may vary.

Actuation of interior lamps
In the event of an ATA alarm, the message "switch on interior lamp - ATA" is placed on the interior CAN by the rear SAM control unit (N10/2).
The overhead control panel control unit (N70) reads this message and actuates the front dome lamp (N70e1) and the rear interior lamp (E15/3).
