GF14.00-P-3000P Emission Control Function

GF14.00-P-3000P Emission Control Function
ENGINES 642.9 in MODEL 164.1 /8, 203.0 /2, 204.0 /2, 221.0 /1, 251.0 /1
- except CODE (474) Particulate filter up to model year 2008 /YoM 07
ENGINES 642.9 in MODEL 209.3 /4, 211.0 /2 /6, 219.3
- except CODE (474) Particulate filter
ENGINES 642.9 in MODEL 461.3
- except CODE (474) Particulate filter
ENGINES 642.8 in MODEL 461.3 up to model year 2010 /YoM 09

The exhaust gases output by the engine are cleaned by the exhaust system and by a near engine mounted primary catalytic converter and a catalytic converter (TWC). The catalytic convertor is also used to reduce noise pollution. The task of exhaust cleaning is to meet the exhaust emission limit values prescribed by the lawmaker through reducing the following pollutants in the exhaust:
^ Nitrogen oxides (NOX)
^ Hydrocarbons (HC)
^ Carbon monoxide (CO)
^ Particulate matter (particles) (PM)

In addition to emission control, exhaust gas recirculation (EGR) and intake port shutoff are used (except model 461). EGR reduces the NOX content and intake port shutoff reduces the PM levels in the emissions (except model 461).
