GF07.16-P-3018P CDI Smooth Running Control, Function

GF07.16-P-3018P CDI Smooth Running Control, Function
ENGINE 642 in MODEL 219.3, 209.3, 211.0 /2, 209.4, 211.6
ENGINE 642 in MODEL 461.3
ENGINE 642.9 in MODEL 463.3 up to 31.5.12
ENGINE 642 in MODEL 221.0, 203.0, 164.1, 203.2, 251.0 /1, 164.8, 221.1 up to model year 2008
/YoM 07

The smooth running control reduces any rough running occurring in idle. To do this the CDI control unit (N3/9) reads in the crankshaft
Hall sensor (B70). The CDI control unit evaluates the signal from the crankshaft Hall sensor for its uniformity.
If deformities occur in the crankshaft Hall sensor signal, the CDI control unit then regulates the fuel pressure in the rail via the pressure regulator valve (Y74) and controls the injection timing via cylinder-specific actuation of the fuel injectors (Y76).
The fuel pressure in the rail and the injection time of fuel injectors produce the injection quantity.
