GF82.70-P-3000PMM Dialing, Function

GF82.70-P-3000PMM Dialing, Function

MODEL 203.0 /2 /7 as of 24.4.04
- with CODE (813) Voice control system (VCS [SBS])
- up to Model Year 8
- Auswahl und Dialog zu den Audiokomponenten (Radio, CD, Kassette)

Function prerequisites:
- The radio (A2), with code (523) MB Audio 20 radio is activated.
- Radio and navigation unit (A2/56) with code (525) MB Audio 50 APS radio is activated.
- COMAND operating, display and control unit (A40/3) with code (527a) COMAND APS (with navigation) is activated.

After activating the voice control system (VCS) with the VCS switch (S93/2), the user has a number of possibilities for establishing a connection to the particular audio system.

To activate the desired audio function, the following radio component activation commands can be used:
- Radio
- Radio on
- Turn radio on
- Turn on radio

The following commands can be used to activate the cassette component:
- Cassette
- Cassette on
- Turn cassette on
- Turn on cassette

The following commands can be used to activate the CD component of the radio (A2), with code (523) MB Audio 20 radio:
- CD
- CD on
- Turn CD on
- Turn on CD

The following commands can be used to activate the CD component of the CD player with changer (in glove compartment) (A2/6), with code (819) CD changer (6-disk):
- CD player
- CD player on
- Turn CD player on
- Turn on CD player
- CDC
- CDC on
- Turn CDC on
- Turn on CDC

If the user is in dialogue mode with the desired component of the particular audio system, they can use additional commands to control the particular audio system.

If the radio component is activated, the following control commands are available:
- Station search
- Different station
- Next station
- Find different station
- Frequency
- Store station (when station list present)
- Select station (when station list present)
- Read station list (when station list is present)
- Read stations (when station list is present)
- Delete station list (when station list is present)
- Delete station
- Traffic radio on/Switch on traffic radio/Traffic radio off
- FM/Long Wave/Middle Wave/Short Wave
- Help/Help radio

If the cassette component is activated, the following control commands are available:
- Different title
- Next title
- Find different title
- Search
- Other side
- Wind cassette forward
- Wind cassette back
- Fast forward
- Fast reverse
- Return flow
- Traffic radio on/Switch on traffic radio/Traffic radio off
- Help/Help cassette

If the CD component of the CD player with changer (in glove compartment) (A2/6), with code (819) CD changer (6-disk) is activated, the following control commands are available:
- CD number xx
- Next CD
- Select next CD/insert next CD
- Different CD
- CD title xx
- CD title number xx

If the CD component of the CD player with changer (in glove compartment) (A2/6), with code (819) CD changer (6-disk), or the CD component of the radio (A2), with code (523) MB Audio 20 radio is activated, the following control commands are available:
- Select track xx
- Select track number xx
- Different track/next track
- Find different track
- Traffic radio on/Switch on traffic radio/Traffic radio off
- Help/Help CD changer/Help CD player

A personal station list can be created with the commands listed above. The sequence is the same as for creating a personal telephone book, however, with the commands listed above.

A help function is available that supports the user in operating the voice control system (VCS). If, for instance, the user is in dialogue mode with the radio component of the particular audio system and says the word "Help", the voice control system (VCS) reads out the most important radio commands. If the user is in the Dialog mode with the cassette component, they can change the system by saying "Help radio" and the voice control system (VCS) then reads the most important radio commands aloud.
