GF82.95-P-2004RMA Emergency Call Telegram Generation, Function

GF82.95-P-2004RMA Emergency Call Telegram Generation, Function
- with CODE (359) TELE AID emergency call system
- TELE AID Telediagnosis


Telediagnosis call (roadside assistance call)
When the MB-Info and breakdown assistance button group (S93/6) is pressed, an SMS is automatically sent to the service center. The following data are automatically transmitted in a roadside assistance call:
^ Vehicle position
^ Vehicle identification data (telephone number)
^ Status data
^ Fault code

MB-Info call
When the user presses the MB-Info and breakdown assistance button group (S93/6), the service is activated. If the service is authorized and no higher-priority service is active, the emergency call system control unit (N123/4) sends an SMS to the service center. The following data are transmitted:
^ Vehicle position
^ Vehicle identification data (telephone number)
