GF82.90-P-3001RL Scanning Of Switch Positions, Function

GF82.90-P-3001RL Scanning Of Switch Positions, Function
- with CODE (428) Steering wheel shift buttons

The switch positions of the following components are read in voltage-coded from steering column module (N80):
^ Left multifunction steering wheel button group (S110)
- Scroll forward/back button (S110s1)
- System selection button (S110s3)
- Fanfare horn system button (S110s5)

^ Right multifunction steering wheel button group (S111)
- Buttons + and - for setting specific functions and volume control (S111s1)
- Accept/terminate phone call button (S111s3)
- Fanfare horn system button (S111s5)

^ Left steering wheel gear shifter (S110/2) and right steering wheel gear shifter (S111/2) (vehicles up to 31.5.06 with code (428) Steering wheel shift buttons)
^ Steering wheel gear shifter MINUS (S110/1) and steering wheel gear shifter PLUS (S111/1) (vehicles as of 1.6.06 with code (428) Steering wheel shift buttons)

Steering column module (N80) detects the respective request and places it on the Controller Area Network bus, class B (interior) (CAN-B).

If several functions are simultaneously requested by a button press, the instrument cluster (A1) will always only activate one function.

Prioritization for simultaneous button press at the left multifunction steering wheel button group (S110):
^ Fanfare horn button (S110s5)
^ System select button (S110s3)
^ Scroll forward/back button (S110s1)

Prioritization for simultaneous button press at the right multifunction steering wheel button group (S111):
^ Fanfare horn button (S111s5)
^ Accept/terminate phone call button (S111s3)
^ Buttons + and - for setting specific functions and volume control (S111s1)
