GF82.85-P-3004T Data Exchange Between the Operating Unit and Instrument Cluster, Function

GF82.85-P-3004T Data Exchange Between The Operating Unit And Instrument Cluster, Function
- with CODE (525) MB Audio 50 APS radio


Operation of the radio control panel and navigation unit (A2/56) via the multifunction steering wheel
With the aid of the left multifunction steering wheel button group (S110), the right multifunction steering wheel button group (S111) and the multifunction display (A1p13) of the instrument cluster (A1), the following systems that are controlled via the MOST can be operated and system information can be displayed: These include:
^ Audio systems (radio, CD changer, etc.)
^ Navigation system
^ Telecommunication system

All the data is exchanged between the instrument cluster (A1) and operating unit via the MOST and the CAN interior (CAN-B).

All the button operations at the multifunction steering wheel are read in voltage-coded by the steering column module (N80) and supplied on the CAN interior (CAN-B).
The instrument cluster (A1) detects the coded messages and initiates, via the multifunction display (A1p13), the presentation of the system which is just active or operated (audio, navigation, telephone).
In parallel with this, the audio gateway control module (N93/1) picks up the commands for controlling the functions within the MOST, converts these into light pulses and with them actuates the necessary system components.

The instrument cluster (A1) receives the current time from the radio control panel and navigation unit (A2/56), since it is automatically received via GPS and thus does not have to be adjusted.

COMAND-specific operating and display options on the multifunction display (A1p13)
Radio display:
^ Set frequency band and where applicable memory location number (e.g. FM1)
^ Name (only for RDS station) and frequency of station
^ Information as to whether the station search takes place via the frequency or the stored station list "SP"

Radio operation:
^ Volume
^ Station search with station list or frequency
^ Next station/previous station

Display of the CD changer (A2/6):
^ Number of CD currently playing
^ Number of CD track currently being played

Operation of the CD changer (A2/6):
^ Volume
^ Selection of track
^ Next track/previous track

Navigation display:
^ Name of the road currently being traveled along
^ Next street to turn off into
^ Distance to next turning point (in units of lengths or as beam diagram)
^ Turnoff arrow

Navigation operation:
^ Volume of voice output

Telephone display:
^ Request to enter PIN number
^ Name of provider
^ Vehicle outside transmit or receive range of telephone network
^ Call number (if stored) or name of caller (if transmitted at the same time with two-way radio)

Telephone operation:
^ Volume
^ Selection of name from stored phone directory, display of phone number and memory location number of party being called.
^ Start making a call
^ Accepting a call
^ Dial repeat
^ Reject or end call
