GF82.95-P-2004PMA Emergency Call Telegram Generation, Function

GF82.95-P-2004PMA Emergency Call Telegram Generation, Function

MODEL 203.0 /2 /7
- with CODE (359) TELE AID emergency call system
- up to Model Year 8
- TELE AID Telediagnose

Telediagnosis call (roadside assistance call)
The MB-Info and breakdown assistance button group (S93/6) is used to automatically send an SMS to the service center.
During a roadside assistance call, the following data are automatically transmitted as an SMS:
- Vehicle position
- Customer identification data
- Vehicle identification data
- Status data
- Error code

MB information call, function
The user activates this service by pressing the MB-Info and breakdown assistance button group (S93/6). If the service is authorized and no higher-priority service is active, the emergency call system control unit (N123/4) transmits an SMS to the service center. The SMS contains the following data:
- Vehicle position
- Customer identification data
- Vehicle identification data
