GF91.29-P-3004T Code-Related Storage Block Selection

GF91.29-P-3004T Code-Related Storage Block Selection
- with CODE (275) Memory package (driver seat, steering column, mirrors)
- up to 30.5.05

Function
The position of the driver seat is stored key-specific in the driver-side front seat adjustment control unit with memory (N32/1).

The EIS [EZS] control unit (N73) converts the currently used key track (depending on the transmitter key) into a memory block number. If key dependency is enabled, there is a standard assignment between the key track and the memory block number as per the following list. This is sent cyclically over the interior CAN.

Key dependency in the instrument cluster (A1): ON

Key track:

1 2 3 to 8

Memory block number from EIS [EZS] control unit (N73):

1 2 3

Memory button of the left front seat adjustment switch group (S91/2) is issued by the left front door control unit (N69/1):

1 2 3 1 2 3 1 2 3

Memory area in the driver-side front seat adjustment control unit with memory (N32/1):

1 2 3 4 5 6 7 8 9

If key-dependency is switched off in the instrument cluster (A1), all the settings are assigned to memory block number 3. If the key-dependency is switched off, the EIS control unit (N73) transmits only the memory block number 3.

The following settings undergo key-related storage:
^ Driver's seat position
^ Steering column position
^ Outside rearview mirror position
^ mirror park position
^ Air conditioning settings
^ Adjustments in instrument cluster (A1)
^ Contour for left dynamic seat, incl. multicontour seat, code 433
