GF00.20-P-2008Q Remaining Time, Function

GF00.20-P-2008Q Remaining Time, Function
- Model 209.3 with ENGINE 112, 113, 271 up to 31.5.05, 612, 646
- Model 209.4 with ENGINE 112, 113, 271 up to 31.5.05

15.03.07 The document has been updated to this date and will no longer be subject to revision.

Remaining time
The remaining distance is displayed in the instrument cluster (A1). It is the time that remains until the next service. The remaining time is only relevant in the case of vehicles with low annual mileage. The remaining distance is generally displayed. The remaining time is dependent:
- on the startup time
- on the driving conditions

Topping the oil up has no influence on the remaining time.

These dependencies have shown the Active Service System (ASSYST) also matches the requirements of a vehicle with a low annual driven distance. Depending on evaluation, the service interval in the case of these vehicles is between one and two years.

Startup time
The startup time refers to the service interval in days immediately following the oil change.
The startup time is not dependent on the driving conditions or any possible oil top-ups.
The startup time is 730 days ((J) 365 days).
The startup time is automatically reset to its initial value by the oil change reset following each oil change. The startup time is an internal operand, and cannot be displayed in the instrument cluster (A1). The starting distance can only be displayed with STAR DIAGNOSIS.

Warning threshold (in days)
With STAR DIAGNOSIS, a warning threshold of between 5 and 30 days, with an increment of one day, can be set for the remaining time. The basic adjustment is 30 days.
