AP83.00-P-8381P Replacing Heater/Ventilation Dust Filter

AP83.00-P-8381P Replacing Heater/Ventilation Dust Filter

Shown on model 203:

DANGER:
- Risk of explosion from explosive gas. Risk of poisoning and caustic burns from swallowing battery electrolyte. Risk of injury with caustic burns to eyes and skin from battery electrolyte or from handling damaged lead-acid batteries.
- No fire, sparks, naked flames or smoking.
- Wear acid-resistant gloves, clothing and eye protection Pour battery electrolyte only into suitable and appropriately marked container.

1 Open snap fasteners (1)
2 Remove dust filter housing (2)
3 Remove dust filter from housing (2)

CAUTION: Dust filter must not be cleaned - replace.

4 Install in the reverse order.
