GF82.61-P-4000QMU Destination-Oriented Navigation In Digitalized MAP Area, Function

GF82.61-P-4000QMU Destination-Oriented Navigation In Digitalized Map Area, Function
- with CODE (530) COMAND APS USA (with navigation system)


During trips within the digitized map area, the following information calculated by the navigation processor of the COMAND operating, display and controller unit (A40/3) is available to the user:
^ The current position and route of the vehicle on a digital map
^ List of routes
^ Distance from the destination and likely time up to arrival
^ Travel direction recommendation
^ Travel direction arrow
^ Name of current road
^ Name of road into which the vehicle is to turn into next
^ Distance to next turning-off point (stated in length units or as a bar graph)

The compass direction North, South, East and West is specified (by graphical representation and voice output). It is displayed only in the case of numbered roads. No data and display of the compass direction is given in the case of roads designated by name (e.g. within towns).

There are 3 types of display available for the destination-oriented navigation:
^ Map
^ Map and symbol presentation of the turn-off points
^ Symbol presentation (system of navigation symbols)

The scale of the map can be changed in stages (100 m/cm to 500 km/cm). It is also possible to choose whether the map should be aligned in the direction of travel or Northwards.

Blaupunkt Travelpilot DX navigation Digital Versatile Disk (DVD)
Separate one-way lanes (fine geometry) are automatically displayed with this DVD.

The DVD type (with the latest fine geometry) is automatically detected and the graphic is displayed in an optimized second set of line thicknesses.
The actual destination-oriented navigation is mainly supported by the voice output.
