GF82.61-P-4000QM Destination-Oriented Navigation In Digitalized MAP Area, Function

GF82.61-P-4000QM Destination-Oriented Navigation In Digitalized Map Area, Function
- with CODE (527) COMAND APS (with navigation)


During trips within the digitized map area, the following information calculated by the navigation processor of the COMAND operating, display and controller unit (A40/3) is available to the user:
^ The current position and route of the vehicle on a digital map
^ List of routes
^ Distance from the destination and likely time up to arrival
^ Travel direction recommendation
^ Travel direction arrow
^ Name of current road
^ Name of the road to turn into
^ Distance to next turning-off point (stated in length units or as a bar graph)

There are 3 types of display available for the destination-oriented navigation:
^ Map
^ Map and symbol presentation of the turn-off points
^ Symbol presentation (system of navigation symbols)

The scale of the map can be changed in stages (50 m/cm to 500 km/cm on the screen). Moreover it is possible to select whether the map is aligned in the direction of travel or facing north.

Blaupunkt Travelpilot DX navigation digital versatile disk (DVD)
Separate one-way lanes (fine geometry) are automatically displayed with this DVD.

The DVD type (with the latest fine geometry) is automatically detected and the graphic displayed in a 2nd optimized set of line thicknesses. The voice output supplements the actual destination-oriented navigation.
