GF82.85-P-2011QM TV-mode, function

GF82.85-P-2011QM TV-mode, Function
- with CODE (527) COMAND APS (with navigation)
- with CODE (860) TV tuner


TV-mode, function
The liquid crystal display (LCD) of the COMAND operating, display and control unit (A40/3) is used for TV reception. TV reception is possible up to approx. 6 km/h and can be activated in the "TV" submenu.

The TV tuner (A2/10) is located on the right sidewall in the trunk.

The audio signals are transmitted via the Media Oriented System Transport (MOST) and the video signals are transmitted via a separate composite color video signal line to the COMAND operating, display and control unit (A40/3). The audio signals are pre-amplified there and the stored tone settings (volume, bass, treble and fader) are implemented.

Search and store station
In TV-mode, the stations can be found and stored using the following functions:
^ Automatic station search
^ Station search with station list
^ Tune into station by selecting channel
^ Station selection via direct channel input
^ Station selection from the station memory

It is possible to store up to 10 stations.

AV mode
Two external devices can be connected to the TV system. Using the right knob, "AV1" or "AV2" can be selected via the menu field.

TV mute, function
The mute function of the audio sources is maintained when it was activated before switching off.

Displaying mute status in the TV screen
If the mute status is set (muting), a mute symbol is displayed at the top right of the screen. It is necessary for the mute status to be transmitted to the TV tuner (MOST) (A2/10) with a newly generated command so that the mute status can be displayed on the TV screen.

The setting which was performed last before switching off the ignition is adopted when the ignition is switched on again.
