AR26.60-P-0600-01A Remove/Install Cross Bridge of Floor Shift

AR26.60-P-0600-01A Remove/Install Cross Bridge of Floor Shift
- TRANSMISSION 716.6 in MODEL 203, 209.3/4, 210









Remove, attach

1 Unscrew crossmember (40) of floor shift.

Installation:

Pay attention to tightening torque.





2 Pry left safety bolt (41a) off support (41) and remove.

Installation:

The safety bolt (41a) must latch in the bore on the support (41)





3 Remove right locking ring (42a).





4 Swivel left support (41) backwards.
5 Pull crossmember (40) out of bolt of right support and remove.
6 Install in the reverse order.
