GF82.95-P-2005QMA Emergency Call Telegram Transmission, Function

GF82.95-P-2005QMA Emergency Call Telegram Transmission, Function
- with CODE (359) TELE AID emergency call system
- TELE AID telediagnosis


In the event of a service call (MB information calls or roadside assistance calls) any currently active telephone connections are interrupted. The emergency call system control unit (N123/4) transmits an SMS to the nearest service center, and, at the same time, it establishes a telephone connection to the emergency call center.
Normally the telephone connections are handled over the telephone antenna (A2/22) (model 209.4, model 209.3 up to 31.5.06) or over the telephone antenna (A2/49a1) (model 209.3 as of 1.6.06), which is located on the roof.

In the event that the telephone antenna (A2/22 or A2/49a1) is defective, the emergency call system control unit (N123/4) actuates the emergency call system left backup antenna (A2/54) and the emergency call system right backup antenna (A2/55) in the rear bumper over the emergency call system antenna splitter (A2/25).
