GF82.95-P-2005Q Emergency Call Telegram Transmission, Function

GF82.95-P-2005Q Emergency Call Telegram Transmission, Function
- with CODE (855) TELE AID
- except CODE (498) Japanese version
- except CODE (491) U.S. version


After a TELE AID emergency call is triggered (automatically or manually), the D2B telephone and TELE AID transmitter/receiver (A35/17) generates an emergency call telegram and transmits it to the service provider (Tegaron company) via mobile telephone (D- net). In the case of an emergency, the D2B telephone and TELE AID transmitter/receiver (A35/17) takes over the sole control of the telephone system to ensure the following:
^ If the telephone is switched off before the emergency alarm is triggered, it is activated.
^ An existing telephone connection is interrupted.
^ The telephone handset (A34) can no longer be operated.

The radio link is established through the telephone system with the aid of the CTEL antenna (A2/22). If the telephone antenna (A2/22) does no longer function due to an accident, the D2B telephone and TELE AID transmitter/receiver (A35/17) switches automatically over to the emergency call system left backup antenna (A2/54) and emergency call system right backup antenna (A2/55). If the power supply is interrupted (e.g., battery interruption), the D2B telephone and TELE AID transmitter/receiver (A35/17) switches automatically over to the additional battery (G1/1). The service provider receives the emergency call. He has a graphic-capable work station with street database. There, among others, the location of the vehicle is determined from the information of the emergency call telegram. The service provider transmits the decoded emergency call telegram to the responsible service center (e.g., police, fire department, German Red Cross).

The emergency call system must be authorized to transmit an emergency call telegram.
