GF82.95-P-2002QM Status Indicator, Location/Function

GF82.95-P-2002QM Status Indicator, Location/function
- with CODE (359) TELE AID emergency call system

The system operates automatically in the event of a crash. The system is activated manually by pressing the SOS pushbutton switch (S93/3). This may be the case for emergency situations or when an accident is spotted. The activated emergency call system is indicated by a flashing red LED in the SOS pushbutton switch (S93/3). If a recall to the vehicle by the emergency call center is not be replied to, a search and rescue operation will be initiated in due course by the local rescue teams. If the emergency call system is unable to establish a connection to the emergency call center or the subscriber identification module (SIM) card has not been authorized, the system automatically calls the police emergency call number "911" and tries to establish a connection via the hands-free system. In this case, no data are transferred by SMS.

SOS pushbutton switch (S93/3)
The SOS pushbutton switch (S93/3) is covered with a safety flap bearing red lettering. The flap is labeled "SOS". By tipping on the safety flap, it is released and opens independently with the help of a spring mechanism. Pressing the SOS pushbutton switch (S93/3) for longer than 0.5 sec. activates the system.

MB-Info and breakdown assistance button group (S93/6)
The MB-Info and breakdown assistance button group (S93/6) is located in the center console next to the UPCI portable CTEL holder (Universal Handy Interface) (A34/15). Pressing the MB-Info and breakdown assistance button group (S93/6) for longer than 0.5 s activates the system. The activated system is indicated by a flashing red LED in the buttons. Pressing a button automatically sends an SMS. At the same time as the SMS is sent, a voice connection to the service center is established immediately

Status reports
The status messages are output in the display of the following components:
^ Radio (A2)
^ COMAND operating, display and control unit (A40/3), with code (530) COMAND APS USA (with navigation)
^ Multifunction display (A1p13) of instrument cluster (A1)
