GF80.45-P-2010Q Convenience Closing With Keyless Go, Function

GF80.45-P-2010Q Convenience Closing With Keyless Go, Function
- with CODE (889) Keyless Go


Function prerequisites
^ Circuit 15c Off
^ Doors closed
^ Vehicle locked
^ Windows and sliding/pop-up roof synchronized

Function
The sliding/pop-up roof (with code 414a) Electric glass sliding/pop- up roof ) and the windows can be closed by pressing and holding down the locking button on the left door handle switch (S17/19) or right door handle switch (S17/21). This closing operation for the sliding/pop-up roof and the windows corresponds to a manual closing operation. The closing request is relayed from
^ the left door handle switch (S17/19) via the left door Keyless go control module (N69/8) or from
^ the right door handle switch (S17/21) via the right door Keyless go control module (N69/9)

to the EIS control module (N73), which acts as a gateway between the Keyless go data bus and CAN class B bus. Via the CAN class B bus, the information is relayed to the overhead control panel control module (N70), to the left door control module (N69/1), right door control module (N69/2) and rear control module (N22/6), which actuate the SR motor (M12m1) and power window motors (M10/3, M10/4, M10/5 and M10/6) in the closing direction accordingly.It is not possible to open the sliding/ pop-up roof and windows with the Keyless go feature.

Emergency opening function
If the locking button on the left door handle switch (S17/19) or right door handle switch (S17/21) is released while the sliding/pop-up roof and windows are being closed with the Keyless go feature, and then actuated again, the sliding/pop-up roof and windows are actuated in the opening direction for 2 s.
