Vacuum Element For Diverter Flap

Illustrated On Model 220:

The right center diverter flap actuator motor (M16/18) is located on the side of the A/C housing.

Component Identification:

The left center diverter flap actuator motor (M16/17) is located on the side of the A/C housing.
