GF91.30-P-2002PP Heated Seats Switch-Over Function

GF91.30-P-2002PP Heated Seats Switch-over Function


Manual switchover

Function requirement:
- The heated seats (HS) are switched on.

Function
Switching the heating stage from "1" to "2" or from "2" to "1" is triggered by one press of the switch position that is not currently active at the left front HS switch (N72/1s10) or the right front HS switch (N72/1s11).

The upper control panel control unit (N72/1) reduces or increases the electric power output of the heated cushions (R13/1, R13/2, R13/3 and R13/4) in the seat depending on the heating stage that has been selected.

Automatically switching to heating stage "1" at the end of the heating-up time

Function requirement:
- The heated seats (HS) are switched on.

Function
If the maximum heating-up time of 5 min has been reached, the upper control panel control unit (N72/1) automatically triggers the switchover from heating stage "2" to heating stage "1".
The upper control panel control unit (N72/1) reduces the electric power output of the heated cushions (R13/1, R13/2, R13/3 and R13/4) in the seat and switches the second LED off.
After another 30 minutes at heating stage "1" the heated seats (HS) are switched off altogether.
