GF68.50-P-0002PC Electric Roller Blind Panoramic Sliding Roof Function

GF68.50-P-0002PC Electric Roller Blind Panoramic Sliding Roof Function

- with CODE (413) Panoramic sliding roof
- up to Model Year 8

Networking of components







1, 3 Retract sun blind
2, 4 Extend sun blind
M24 Sun blind drive unit
M24m1 Sun blind motor
N70 Overhead control panel control module

The panoramic sliding roof comprises a movable front glass panel and a stationary rear glass panel.
Additional sun protection is provided by two electrically powered sun blinds installed in the center bar of the roof. These cover the interior of the front movable glass panel and the rear stationary glass panel.

Function requirements
- Circuit 15R ON or
- Circuit 15 ON

Function
The sun blind drive unit (M24) is operated using the sliding/tilting roof switch (N70s1).

The sliding/tilting roof switch (N70s1) can be used to deploy the following functions:
- Manually close/open sun blind
- Automatically open sun blind

The convenience feature function with the sub-functions convenience closing and convenience opening closes/opens the sun blind by means of the "Lock"/"Unlock" buttons on the transmitter key (A8/1).
