Removal and Replacement

AR05.10-P-7800C Remove/Install Chain Tensioner
ENGINE 112.945 in MODELS 463.209 /232 /233 /244 /245 /250
ENGINE 112 in MODELS 163, 129
ENGINE 113.962 in MODELS 463.206 /240 /241 /247 /248 /249 /254
ENGINE 113 (except 113.965 /981) in MODELS 210, 208, 202, 163, 129
ENGINE 113.982 in MODELS 463.243 /246





Shown on ENGINE 112 in MODEL 129

1 Viscous fan
2 Fan shroud
3 Poly-V-belt
4 Alternator
5 Timing case cover
6 Chain tensioner
7 Sealing ring
