GF82.95-P-2006P Voice Connection to Vehicle, Function

GF82.95-P-2006P Voice Connection To Vehicle, Function

MODELS 203, 210, 220 up to 31.8.03
- with CODE (855) TELE AID
- with CODE (930) Taxi emergency call
- for a TELE AID emergency call
MODELS 208.3, 215 up to 31.8.03
- with CODE (855) TELE AID
- for a TELE AID emergency call

After the service center (police, fire brigade, German Red Cross, ...) has received a TELE AID emergency call telegram a radio connection is completed to the vehicle to interview passengers or persons involved. This allows rescue measures to be started depending on the actual severity of the accident.
The radio connection between the vehicle and the responsible service center is completed in the vehicle via the telephone system. If the telephone antenna (A2/22) (model 215), (A2/49a1) (models 203, 208, 210, 220) is no longer working due to an accident, the vehicle automatically switches over to the TELE AID backup antenna (A2/50). If the power supply has collapsed (battery sheared off), the system switches over automatically to the backup battery (G1/1).

The voice connection is completed over the hands-free system microphone (B25) and the emergency call system loudspeakers or the hands-free system (model-dependent).

Peculiarities on taxi emergency call (code 930):
The voice connection is normally limited to listening to the vehicle passenger compartment via the hands-free system microphone (B25), otherwise the threatening person may be warned or panicked. The service center only attempts to obtain additional information in special cases by asking questions.
