GF82.95-P-2005P Emergency Call Telegram Transmission, Function

GF82.95-P-2005P Emergency Call Telegram Transmission, Function

MODELS 203, 210, 220 up to 31.8.03
- with CODE (855) TELE AID
- with CODE (930) Taxi emergency call
- for a TELE AID emergency call
MODELS 208.3, 215 up to 31.8.03
- with CODE (855) TELE AID
- for a TELE AID emergency call

After a TELE AID emergency call has been triggered (automatically or manually) the D2B telephone and TELE AID transmitter/receiver (A35/17) generates an emergency call telegram and the transmits it to the service provider via mobile telephone (D-network).

In the case of an emergency the D2B telephone and TELE AID transmitter/receiver (A35/17) take over the sole control of the telephone system to ensure the following:
- If the telephone is switched off before an emergency alarm is triggered, it is activated
- a possible present telephone connection is interrupted,
- the telephone can no longer be operated using the telephone handset (A34).

The radio connection is made via the telephone system with the aid of the telephone antenna (A2/22) (model 215), (A2/49a1) (models 203, 208, 210, 220).
If the telephone antenna (A2/22) (model 215), (A2/49a1) (models 203, 208, 210, 220) is not longer working as a result of an accident, the D2B telephone and TELE AID transmitter/receiver (A35/17) automatically switches to the TELE AID backup antenna (A2/50). If the power supply is interrupted (for example battery interruption) the D2B telephone and TELE AID transmitter/receiver (A35/17) switches automatically over to the additional battery (G1/1).

The service provider receives the emergency call. He has a graphic- capable workstation with road data base. There, among others, the location of the vehicle is determined from the information of the emergency call telegram. The service provider transmits the decoded emergency call telegram to the responsible service center (police, fire brigade, German Red Cross, ....).

Peculiarities on taxi emergency call (code 930):
TELE AID transmits its current position to the emergency call center every 45 seconds during a taxi emergency call.

The emergency call system must be authorized to transmit an emergency call telegram.
