GF82.95-P-2004PA Emergency Call Telegram Generation, Function

GF82.95-P-2004PA Emergency Call Telegram Generation, Function

MODELS 203, 210, 220 up to 31.8.03
- with CODE (855) TELE AID
- with CODE (930) Taxi emergency call
- for a TELE AID emergency call
MODELS 208.3, 215 up to 31.8.03
- with CODE (855) TELE AID
- for a TELE AID emergency call

After a TELE AID telediagnosis is activated, the D2B telephone and TELE AID transmitter/receiver (A35/17) automatically generates an emergency call message. It includes the following information:
- Location of the vehicle: degrees longitude and latitude
- Data for vehicle identification
- Model, model year, type of engine

- Information on current vehicle status
- Engine temperature
- Mileage
- Battery voltage
- Displayed malfunction and warning messages

The emergency call telegram is transmitted to the Mercedes Benz Customers Assistance Center (CAC) via mobile telephone (digital network) and is automatically decoded there to start corresponding help measures.

TELE AID telediagnosis does only operate when the system is authorized.
