GF82.95-P-2004P Emergency Call Telegram Generation, Function

GF82.95-P-2004P Emergency Call Telegram Generation, Function

MODELS 203, 210, 220 up to 31.8.03
- with CODE (855) TELE AID
- with CODE (930) Taxi emergency call
- for a TELE AID emergency call
MODELS 208.3, 215 up to 31.8.03
- with CODE (855) TELE AID
- for a TELE AID emergency call

After an emergency call is triggered the D2B telephone and TELE AID transmitter/receiver (A35/17) automatically generates an emergency call telegram.
It includes the following information:
- Location of the vehicle: degrees longitude and latitude
- Type of emergency call activation: automatically or manually with the TELE AID pushbutton switch (S93/3) or the emergency call actuation button (S62/6) (taxi emergency call only)
- Crash parameter from restraint system control unit (N2/7) and from external tilting cone sensor (B66),
- Identification number for identifying vehicle,
- Time of emergency call.

The emergency call telegram is relayed to the service provider via mobile telephone (digital network) and is automatically decoded there.

Up to three emergency call telegrams are stored in the D2B telephone and TELE AID transmitter/receiver (A35/17) . If already more than three emergency call telegrams are stored the oldest telegram is written over. During a taxi emergency call the current vehicle position is stored every 10 minutes in addition.
