GF82.95-P-2003P Emergency Call Actuation, Function

GF82.95-P-2003P Emergency Call Actuation, Function

MODELS 203, 210, 220 up to 31.8.03
- with CODE (855) TELE AID
- with CODE (930) Taxi emergency call
- for a TELE AID emergency call
MODELS 208.3, 215 up to 31.8.03
- with CODE (855) TELE AID
- for a TELE AID emergency call

A TELE AID emergency call can be triggered automatically or manually:
Manually:
- With the aid of the SOS pushbutton switch (S93/3s1), if the vehicle is not involved itself in an accident or the driver requires help.
- with the aid of the emergency alarm actuation switch (S62/6) (only with code 930, taxi emergency call).
For diagnostic purposes, manually with Star Diagnosis.

Automatically:
- via the restraint system control unit (N2/7) when an airbag/ sidebag is actuated or in the event of severe rear-end collision.
- When the external tilting cone sensor (B66) recognizes a rollover and transmits it to the D2B telephone and TELE AID transmitter/receiver (A35/17) or
- if the rollover sensor in the TELE AID control unit (A35/8) (models 208, 210, 215, 220) registers a rollover.

A TELE AID emergency call is completed when the service center terminates the voice connection.

Emergency call priority
The information how an emergency call is triggered is entered into the emergency call telegram generated by the D2B telephone and TELE AID transmitter/receiver (A35/17) . The types of actuation have various priorities.

Highest priority:
1. Automatic emergency call
2. Manual taxi emergency call with (S62/6 (only with code 930, taxi emergency call)
3. Manual emergency call with SOS pushbutton (S93/3)
4. Telediagnosis call with corresponding button on telephone handset (A34)

Lowest priority:
5. MB Info via relevant menu on telephone handset (A34) (see owner's manual)

If an emergency call is already active when an emergency is actuated this active call is terminated. The emergency call with the lower priority is not started.
If an emergency call with lower priority is already active when triggering, this call is interrupted and the emergency call with the higher priority is started.

Peculiarities on taxi emergency call (only with code 930)
A taxi emergency call should not be noticed by the person(s) posing the threat. For this purpose the emergency alarm actuation button (S62/6) is concealed in the driver's footwell. An indicator lamp, which confirms that the emergency alarm system activate button (S62/6) has been pressed, may be installed as an option. It illuminates for 2 minutes after a taxi emergency call is triggered. The indicator lamp is installed so that only the driver can recognize when it flashes. Moreover, it is ensured that in the event of a taxi emergency call:
- When no dial or ring tone can be heard,
- the dialing procedure is carried out silently,
- the status indicator is not activated in the SOS pushbutton switch (S93/3)
- the volume of the radio cannot be decreased or the radio cannot be set to mute.
- no confirmation messages can be received from the service provider or the police.

The police monitors the passenger compartment via the hands-free system on a taxi emergency call and decides if a voice connection should be completed.

The taxi emergency call can be terminated:
- by the police
- automatically by the D2B telephone and TELE AID transmitter/ receiver (A35/17) after approximately 90 minutes
- when an automatic TELE AID emergency call is triggered.

A TELE AID emergency call or taxi emergency call can only be triggered in emergencies. The telephone system cannot be used during an emergency call.
