Remove/Install Rear Window Molding








Trunk lid
Open.

Bottom molding (Fig. 1)
Press off with plastic wedge.

Side molding (Fig. 2)
Press off with plastic wedge and close trunk lid.

NOTE: Protect paint when pressing off.

Fender (Fig. 3)
Cover with rags.

Cover (Fig. 4)
Slide to side with plastic wedge and press off top molding.

Installation
Install in opposite order.
