Preparation For Test - Section 22

1. Battery voltage 11-14 V.
2. Check fuses.
3. Radio OK.
4. Loudspeaker for sound system installed (Marking: blue label).
5. Connections to N40/3 OK.

See Electrical Wiring Diagrams

NOTE: To prevent damage to the radio and left/right audio power amplifier, the connectors must only be removed or installed with the ignition and radio OFF.

Special Tools:

Description Brand, model, etc.
Digital multimeter 1) Fluke models 23, 83, 85, 87

1) Available through the MBNA Standard Equipment Program.
