Mercedes Benz
>>
1999
>>
C 230K (202.024) L4-2.3L SC (111.975)
>>
Repair and Diagnosis
>>
Heating and Air Conditioning
>>
Testing and Inspection
>>
Component Tests and General Diagnostics
>>
Component Tests
>>
Electrical Test Program [ETP]
>>
ETP - Connection of Components [21]
>>
Air Conditioning (A/C)
Air Conditioning (A/C)
Air Conditioning (A/C)
Models 202 (as of MY 1996)
Electrical Test Program [ETP] - Connection of Components
