Electrical Test Program

Preparation for Test
1. Battery voltage 11 - 14 V.
2. Check fuses.

NOTE: To prevent damage to the radio, the connectors must only be removed or installed with the ignition OFF.

Special Tools

Special Tools:

Radio removal tool
Description Part No.
Removal tool (1 set = 2 pieces) 000 833 03 61


Conventional tools, test equipment
Description Brand, model, etc.
Multimeter 1) Fluke Models 23, 77 III, 83, 85. 87, 88
Signal generator 1) SUN DTR-8416

1) Available through the MBNA Standard Equipment Program
