Power Door Lock Actuator: Service and Repair

AR72.29-D-5910H Remove, Install Motor For Upper Lock On Electric Sliding Door

- with CODE (D03) Roof and rear-end doors, high version
- with CODE (T50) Electrical closing assist for right sliding door
- with CODE (T51) Electrical closing assist for left sliding door


- with CODE (D03) Roof and rear-end doors, high version
- with CODE (T55) Electrical actuation for right sliding door
- with CODE (T56) Electrical actuation for left sliding door







1 Additional lock
2 Cable
3 Cable
4 Cable tie
5 Electrical connector
6 Carrier plate
7 Bolts
8 Bolts
M14/31 Right sliding door ZV additional lock actuator
M14/32 Left sliding door ZV additional lock actuator
N69/6 Right sliding door control unit
N69/7 Left sliding door control unit
