GF72.29-D-2013H Automatic Open/Close, Function

GF72.29-D-2013H Automatic Open/Close, Function

- with CODE (T55) Electrical actuation for right sliding door

- with CODE (T56) Electrical actuation for left sliding door

Function requirements:
- Electric load compartment sliding door (E-LST) is normalized
- Correct rotation direction of right sliding door drive (M73/1) or left sliding door drive (M73/2)
- Active excess force limiter
- Actuation of left sliding door button (N72/1s1) or right sliding door button (N72/1s11), right sliding door button (S159/1) or left sliding door button (S159/2) or transmitter button "Unlock sliding door, rear-end door and open/close sliding door" in transmitter key (A8/1)

Open (one-touch actuation)

When this function is used, the left E-LST or the right E-LST is opened to the rearmost position.

Function interruption in the event of:
- Blockage detection
- Opposite direction button motion
- Incorrect rotation direction of left or right sliding door drive
- Actuation of excess force limiter

Inhibit opening function while driving

The opening and reversing function is inhibited after reaching a certain vehicle speed. This function is relevant for safety.

The right sliding door control unit (N69/6) or left sliding door control unit (N69/7) receives the vehicle speed signal from the following control units separately, in order to evaluate them independently in the event of implausible data:
- Instrument cluster (A1)
- EIS [EZS] control unit (N73)

Close (one-touch actuation)

When this function is used, the left E-LST or the right E-LST is opened to the rearmost position, i.e. lock is in main catch.

Function interruption in the event of:
- Zero point tolerance exceeded
- Blockage detection
- Opposite direction button motion
- Incorrect rotation direction of left or right sliding door drive
- Actuation of excess force limiter
