GF72.29-D-2012HC Actuate Electric Load Component Sliding Door (E-LST), Function

GF72.29-D-2012HC Actuate electric load component sliding door (E-LST), function

- with CODE (T55) Electrical actuation for right sliding door B-pillar sliding door button


- with CODE (T56) Electrical actuation for left sliding door B-pillar sliding door button

Function requirements for opening:
- No overvoltage or undervoltage
- Actuate right sliding door button (S159/1) or left sliding door button (S159/2) once

Opening sequence:
- Right sliding door control unit (N69/6) or left sliding door control unit (N69/7) to opening assist
- signal "Open E-LST lock"

- E-LST lock to right sliding door control unit or left sliding door control unit
- signal "Lock actuated" of right sliding door CL rotary tumbler switch (M14/27s1) or left sliding door CL rotary tumbler switch (M14/28s1)

- Right sliding door control unit or left sliding door control unit to right sliding door drive (M73/1) or left sliding door drive (M73/2)
- The right sliding door drive or left sliding door drive moves the E-LST in the "E-LST open" position

The anti-pinch protection is active during the complete opening path.
When the child safety lock is actuated, actuation of the right sliding door button or left sliding door button is possible only when the E-LST is closed.

Actuation of left sliding door button or right sliding door button when the "Opening" function is activated

When reactuated, the E-LST stops.

If the right sliding door button or left sliding door button is reactuated, the E-LST moves to the "Close" direction.

Function requirements for closing:
- No overvoltage or undervoltage
- Right sliding door button or left sliding door button actuated once

Closing sequence:
- Right sliding door control unit or left sliding door control unit transmit to right sliding door drive or left sliding door drive
- The right sliding door drive or left sliding door drive moves the E-LST in the "E-LST closed" position

- E-LST lock to right sliding door control unit or left sliding door control unit
- signal "Door closed" of right sliding door CL rotary tumbler switch or left sliding door CL rotary tumbler switch to right sliding door control unit or to left sliding door control unit

The anti-pinch protection is active up to the pre-locking position.

Actuation of left sliding door button or right sliding door button when the "Closing" function is activated

When reactuated, the E-LST stops.

If the right sliding door button or left sliding door button is reactuated, the E-LST moves to the "Open" direction.
