GF72.30-D-3004HA Close Door With Closing Assist (CA), Function

GF72.30-D-3004HA Close Door With Closing Assist (CA), Function

- with CODE (T50) Electrical closing assist for right sliding door
- with CODE (T16) Right load compartment sliding door


- with CODE (T51) Electrical closing assist for left sliding door
- with CODE (T19) Left sliding door


- with CODE (T50) Electrical closing assist for right sliding door
- with CODE (T51) Electrical closing assist for left sliding door
- with CODE (T16) Right load compartment sliding door
- with CODE (T19) Left sliding door

Function requirements:
- Closing assist (CA) in extended position
- Auxiliary lock on vehicles with code (D03) Roof and rear-end doors, high version or with code (D05) Super high roof, opened.
- Sliding door open and right sliding door CL rotary tumbler switch (M14/27s1) or left sliding door CL rotary tumbler switch (M14/28s1) signal status "open".

As soon as the rotary tumbler is in the main catch, the right sliding door control unit (N69/6) or left sliding door control unit (N69/7) receives a corresponding signal from the right sliding door CL rotary tumbler switch or the left sliding door CL rotary tumbler switch integrated into the corresponding door lock.

The corresponding control unit actuates the right sliding door closing assist motor (M76/1) or left sliding door closing assist motor (M76/2) which pulls the striker toward the inside.This closes the sliding door completely.Then the rotary tumbler in the auxiliary lock is closed by the right sliding door CL auxiliary lock motor (M14/31m1) or left sliding door ZV additional lock motor (M14/32m1) using control cable.

The rotary tumbler of the auxiliary lock is released again after successful closing by retraction of the drive.
