GF72.30-D-3004H Close Door With Closing Assist (CA), Function

GF72.30-D-3004H Close Door With Closing Assist (CA), Function

- with CODE (T50) Electrical closing assist for right sliding door
- with CODE (T55) Electrical actuation for right sliding door


- with CODE (T51) Electrical closing assist for left sliding door
- with CODE (T56) Electrical actuation for left sliding door


- with CODE (T50) Electrical closing assist for right sliding door
- with CODE (T51) Electrical closing assist for left sliding door
- with CODE (T55) Electrical actuation for right sliding door
- with CODE (T56) Electrical actuation for left sliding door

Function requirements:
- SHI in extended position
- Auxiliary lock on vehicles with code (D03) Roof and rear-end doors, high version or with CODE (D05) Super high roof, opened
- Sliding door open and right sliding door CL rotary tumbler switch (M14/27s1) or left sliding door CL rotary tumbler switch (M14/28s1) signal status "open".

Function sequence

As soon as the right sliding door CL rotary tumbler switch or left sliding door CL rotary tumbler switch signals the main catch position, the striker of the SHI moves to the retracted position. Then the rotary tumbler on the auxiliary lock is closed by the right sliding door CL auxiliary lock motor (M14/31m1) or left sliding door ZV additional lock motor (M14/32m1) using a control cable.

The rotary tumbler of the auxiliary lock is released again after successful closing by retraction of the drive.

When closing the SHI, it is irrelevant whether the sliding door is closed electrically or manually.
