GF72.30-D-3003HA Open Door With Closing Assist (CA), Function

GF72.30-D-3003HA Open Door With Closing Assist (CA), Function

- with CODE (T50) Electrical closing assist for right sliding door
- with CODE (T16) Right load compartment sliding door


- with CODE (T51) Electrical closing assist for left sliding door
- with CODE (T19) Left sliding door


- with CODE (T50) Electrical closing assist for right sliding door
- with CODE (T51) Electrical closing assist for left sliding door
- with CODE (T16) Right load compartment sliding door
- with CODE (T19) Left sliding door

Function requirements:
- SHI in retracted position
- Auxiliary lock on vehicles with code (D03) Roof and rear-end doors, high version or with CODE (D05) Super high roof, closed
- Sliding door in completely closed position

Function sequence

As soon as the rotary tumbler exits the main catch position, opening of the sliding door is recognized.

The striker then moves to the extended position and remains there.The rotary tumbler of the auxiliary lock opens when the associated locking pawl is actuated.
