GF72.30-D-3003H Open Door With Closing Assist (CA), Function

GF72.30-D-3003H Open Door With Closing Assist (CA), Function

- with CODE (T50) Electrical closing assist for right sliding door
- with CODE (T55) Electrical actuation for right sliding door


- with CODE (T51) Electrical closing assist for left sliding door
- with CODE (T56) Electrical actuation for left sliding door


- with CODE (T50) Electrical closing assist for right sliding door
- with CODE (T51) Electrical closing assist for left sliding door
- with CODE (T55) Electrical actuation for right sliding door
- with CODE (T56) Electrical actuation for left sliding door

Function requirements:
- Closing assist (CA) in retracted position
- Auxiliary lock on vehicles with code (D03) Roof and rear-end doors, high version or with code (D05) Super high roof, closed
- Sliding door in completely closed position

In addition, a request to open a sliding door by actuating one of the following components:
- Outer and inner door handle via right sliding door button (S159/1) or left sliding door button (S159/2)
- Transmitter button "Unlock sliding door, rear-end door and open/close sliding door" in transmitter key (A8/1)
- Left sliding door button (N72/1s1) in OBF control unit (N72/1)
- Right sliding door button (N72/1s11) in OBF control unit

The SHI striker moves the extended position and remains there. The rotary tumbler of the auxiliary lock opens when the associated locking pawl is actuated.
